Wagner Audi 8V RS3 EVO3.X 600HP+ Competition Intercooler Kit

Wagner Tuning's competition intercooler EVO3 Audi RS3 8V now available with TÜV certificate and two different intercooler core options.

The new core option EVO3.X was developed in cooperation with a renowned German Audi tuner and is suitable for higher-performance applications 600PS+. The size of the intercooler remains unchanged from the original version. Only the internal core design has been further optimised for the high power applications and guarantees optimal airflow and excellent cooling performance. For all power applications below the 600PS we recommend to use the standard version.

The high-performance intercooler has the following core dimension (515mm x 367mm x 95mm = 16,5L/14,45Inch x 3,74Inch = 1006,9Inch³) and this offers a 84% larger cooling surface and 101% more charge air volume compared to the original intercooler. Our engineers have increased the intercooler core size and efficiency, as well as improved the end tank design to remove any OEM bottlenecks, resulting in increased flow rating and charge cooling properties. This Audi RS3 intercooler uses our award-winning WAGNERTUNING Competition Intercooler Core, which is made specifically for this application. Constructed of the highest quality TUBE and FIN intercooler cores with inside turbulators combined with cast aluminium end tanks optimised by CFD for best possible internal airflow. With the help of additional air guides, inside inlet, a uniform filling of the intercooler is provided. The result is excellent cooling properties with minimum pressure drop. So this kit is just the right thing for racing. The intercooler and the crossmember form a stable unit and weigh only 14,1 kg. It is mounted to the original mounting points and is easy to perform (1:1 exchange). Optimum cooling of the charged air with a clear increase in performance! 68mm (2,67Inch) in- and outlets.

Please note: ACC equipped cars my require recalibration of the ACC Sensor

COMPARISONS

OEM intercooler:

cooling surface 1024cm²(158,7Inch²)
charge-air-volume 8,2L (500,4Inch³)

WT EVO3 Competition:

cooling surface 1890cm² (293Inch²)
charge-air-volume 16,5L (1006,9Inch³)

WHAT'S IN THE BOX?

- 1 intercooler including crossmember
- 1 mounting material
- 1 installation instruction
- 1 TÜV Certification

COMPATIBILITY

- Audi RS3 8V (04/2015 - 04/2016)
RS3 Sportback 270KW/367PS
- Audi RS3 8V (08/2017+)
Sportback/Sedan 294KW/400PS
