The CSF Universal Dual-Pass Oil Cooler, featuring M22 x 1.5 connections and compact dimensions of 13L x 4.75H x 2.16W inches, represents a highly versatile and durable solution within the CSF product range. Engineered to accommodate a wide variety of mounting configurations, this oil cooler offers exceptional adaptability that surpasses conventional oil cooler designs. Its robust bar/plate core construction ensures reliable performance even in environments prone to debris accumulation, where traditional coolers might be vulnerable to puncture and failure.
Distinguished by its innovative design, the CSF oil cooler provides significant advantages over standard plate-type or stacked oil coolers. Its elongated rectangular shape enables installation in confined spaces or vehicle areas with limited vertical clearance, thereby expanding the possibilities for optimal placement. This design also mitigates common airflow challenges associated with stacking multiple coolers, which can adversely affect the efficiency of the vehicle’s overall cooling system.
Another key benefit lies in the strategic placement of the inlet and outlet ports on the same side of the unit, equipped with universal M22 x 1.50 female fittings angled at 40 degrees. This configuration simplifies the routing of oil lines, eliminating the need for complex cross-over plumbing that is often required with traditional coolers. The compatibility with M30 / -16AN / -12AN union adapters further enhances installation flexibility and integration with existing systems.
CSF’s oil cooler is engineered to endure high peak burst pressures, ensuring exceptional durability and reliability under demanding conditions. This resilience makes it suitable for installation in areas exposed to significant debris impact, such as front fascias, differential coolers, or side vents. Additionally, the cooler’s construction is designed to withstand substantial vibration, maintaining consistent performance and longevity even in rigorous operational environments.
Features
- 8 rows of high-pressure bar/plate oil cooling for efficient heat dissipation
- Dual-pass design to maximize cooling capacity and oil flow
- Universal M22 x 1.50 female fittings on the same side (feed and return) with a 40-degree angle for easier line routing
- Compatible with M30 / -16AN / -12AN union adapters for versatile installation options
- Compact dimensions of 13'L x 4.75'H x 2.25'W, facilitating installation in tight spaces
Applications
| Year Range | Make | Chassis Code | Model | Trim | Engine / Trans / Etc | Notes |
|---|---|---|---|---|---|---|
| 0 | Universal | - | - | - | - | - |
| 0 | - | - | - | - | - | Universal |
OEM Part Numbers
- *Universal
Warranty
Cooling Systems and Flexibles, Inc. (CSF) provides a warranty for its High-Performance Cooling Systems, including this oil cooler, under normal use and service conditions. The warranty is extended to the original purchaser of the vehicle in which the product was initially installed. For comprehensive warranty terms and conditions, please visit our Warranty Page.
SKU# 8119 Warranty Term: 2 years
In summary, the CSF Universal Dual-Pass Oil Cooler is a premium-quality product designed to meet the rigorous demands of automotive oil cooling applications. Its compact size, robust construction, and flexible installation options make it an ideal choice for professionals seeking reliable and efficient cooling solutions. Whether installed in high-debris environments or confined spaces, this oil cooler delivers consistent performance, durability, and ease of integration, aligning with the highest industry standards for quality and reliability.
